9146-302 AED Battery for Cardiac Science Powerheart G3 Plus 12V

Product Overview

The 9146-302 is a 100% brand new medical-grade 12V Li-SO2 (Lithium Sulfur Dioxide) long-life primary battery for the Cardiac Science Powerheart AED G3, G3 Plus and G3 Elite series defibrillators. It delivers years of standby power and life-critical reliability for emergency response. This is a non-rechargeable primary battery - do not attempt to recharge it. It replaces part numbers 9146, 9146-001, 9146-002, 9146-102, 9146-202 and 9146-302. Ships 100% brand new with a 1-year warranty.

Specifications

Attribute	Details
Standard Model	9146-302
Capacity	Long-life primary battery (non-rechargeable)
Voltage	12V
Battery Type	Li-SO2 (Lithium Sulfur Dioxide), non-rechargeable
Cell	Made in China, high quality guarantee
Color	Black
Condition	Replacement Battery (100% Brand New, 1-year warranty!)

Replace Part Numbers

• 9146
• 9146-001
• 9146-002
• 9146-102
• 9146-202
• 9146-302

Compatible Models

For Cardiac Science Powerheart AED

• Powerheart AED G3
• Powerheart AED G3 Plus
• Powerheart AED G3 Elite
• Cardiac Science G3 Series

FAQ

Is the 9146-302 battery rechargeable?

No. The 9146-302 is a long-life Li-SO2 primary battery built for years of standby power. It is non-rechargeable - never attempt to recharge it or place it in a charger.

How do I check the AED self-test status before a rescue?

The Powerheart G3 runs automatic daily, weekly and monthly self-tests of battery capacity and circuitry. 1) Confirm the status indicator on the front of the AED shows the ready (green) state. 2) Listen for any audible alert during the self-test window. 3) If you hear the "Battery Low" alert or see a red status indicator, the installed 9146 battery has insufficient power - replace it immediately. 4) After fitting a new 9146-302 pack, confirm that the self-test returns to the ready state.

What part numbers does this battery replace?

It replaces 9146, 9146-001, 9146-002, 9146-102, 9146-202 and 9146-302. Confirm the code on your original pack before ordering.

How long does the battery last in standby?

As a long-life primary pack it typically provides several years of standby power under normal conditions, but always follow the AED manufacturer's replacement schedule and the device self-test status.
