SunEnergyXT 500 / 500 PRO complete storage set with 4× 500 W solar modules

The SunEnergyXT 500 / 500 PRO complete storage set with 4× 500 W solar modules It combines solar power generation, battery storage, and an inverter into a balcony power plant with storage for private households. The storage unit offers a nominal capacity of 5,024 kWh, four MPPT inputs, and, depending on the model, 800 W or 2.400 W of grid-connected AC power. With B500 With the addition of expansion batteries, the selected storage capacity increases up to 30 kWh.

Delivery

1× SunEnergyXT 500 or 500 PRO depending on the selected variant
4× Jollywood JW-HD108N-R2 500-W-Glass-Glass-Fullblack-Solar module
1 x 3 m Schuko AC power cable
1× Mounting kit for the storage unit
1× User manual
0–5× SunEnergyXT B500 extension battery according to selected storage capacity
1× Mounting kit for four solar panels when selecting a mounting option

Produktvorteile

-- 5,024 kWh LiFePO₄ base storage: The storage unit absorbs excess solar power and makes it available later for self-consumption.

-- Four independent MPPT inputs: Several suitable solar modules can be controlled separately within the permissible input values.

-- Model-dependent AC power: The SunEnergyXT 500 delivers up to 800 W, the 500 PRO up to 2.400 W of mains-connected AC power.

-- Complete set with four 500W modules: Generation and storage are combined in a selectable system configuration.

-- Selectable storage capacity: The system can be expanded up to 30 kWh with B500 extension batteries.

Compatibility

The solar modules must be operated within the permissible electrical input values ​​of the selected SunEnergyXT model. For the SunEnergyXT 500, the current regulations for plug-and-play generation systems apply; the connection of the 500 PRO and any permanent integration into the home grid must be inspected by a qualified electrician. Expansions are only permitted using approved SunEnergyXT B500 battery modules.

Technical information

-- Basic storage: 5,024 kWh LiFePO₄
-- PV inputs: 4 MPPT
-- Mains-connected AC power: up to 800 W for the 500; up to 2.400 W for the 500 PRO
-- Storage protection rating: IP65
-- Expansion: up to five B500 modules, maximum 30 kWh total capacity

expandability

The selectable storage capacity consists of the 5,024 kWh main storage unit and zero to five B500 expansion batteries. Before any expansion, the firmware version, permissible number of modules, stack configuration, and manufacturer's installation specifications must be checked.

Matching accessories and related products

• SunEnergyXT B500 5,024 kWh expansion battery for 500 / 500 PRO for the approved storage expansion.

Why Mini Power

In this SunEnergyXT 500 / 500 PRO Complete Set The model, storage capacity, and mounting option are crucial before ordering. Mini Power provides a clear comparison of the different options and indicates which components depend on the selected choice. This allows you to consider PV input power, desired AC power, available installation space, and future expansion possibilities. For questions regarding system configuration, we offer clear and reliable product-related advice based on the latest manufacturer documentation.

Frequently asked questions

-- What is the difference between the SunEnergyXT 500 and the 500 PRO?

The SunEnergyXT 500 offers up to 800 W, and the 500 PRO up to 2.400 W of mains-powered AC output. Connection type and installation requirements must be checked for the selected model.

-- How is the chosen storage capacity achieved?

The main storage unit provides 5,024 kWh. Each selected B500 expansion battery adds another 5,024 kWh; a maximum of five B500 modules are possible.

-- Are solar panel mounts always included?

No. A mounting kit is only included if a corresponding mounting option is selected. If "Without mounting," no module mounting brackets are supplied.
